BOLT Electric Trim Tab Systems

Balance loads, plane faster, increase efficiency and performance with Bennett BOLT Electric Trim Tab systems. BOLT is built to outlast any electric trim tab system on the market.

Search on Google Shopping

Description & Features

Exceptionally durable and dependable electric trim tab systems

  • Lifetime warranty for electric actuators
  • Water-tight design provides trouble-free operation for years
  • Solid construction is built to last
  • Installation is fast and simple
  • Multiple control options, tab sizes, and mounting options available

Items Included in Sets

  • (2) Stainless steel trim planes (tabs) and mounting plates
  • (2) 20ft. harnesses with waterproof connectors (BAW2020)
  • (2)  12-volt actuators with 6ft. wire harnesses and waterproof connectors (BEA2000 OR BEA3000)

Controls Sold separately

Set Options & Tab Sizes

BOLT Electric – Standard Trim Tab Kits with fixed upper hinge actuators (BEA2000)


  • BOLT129 – 12″x9″ trim tabs
  • BOLT189 – 18″x9″ trim tabs
  • BOLT249 – 24″x9″ trim tabs
  • BOLT121 – 12″x12″ trim tabs
  • BOLT1812 – 18″x12″ trim tabs
  • BOLT2412 – 24″x12″ trim tabs

BOLT Electric – Edge Mount Limited Space Trim Tab Kits with adjustable upper hinge actuators (BEA3000)


  • BOLT124 – 12″x4″ trim tabs
  • BOLT612ED – 6″x12″ trim tabs
  • BOLT912ED – 9″x12″ trim tabs
  • BOLT121ED – 12″x12″ trim tabs

Conversion Kits

Product Specs

Product Specs

  • Vertical transom space required:
    • Fixed upper hinge (BEA2000): 13″
    • Adjustable upper hinge (BEA3000): 6.39″
  • Stroke: 2.5″
  • Length: 13.25″
  • Voltage: 12V
  • Connectors: Deutsch, DT Series, 13A
  • Working forces:
    • Actuation force: 750 lb.
    • Return Force: 750 lb.
  • Current draw:
    • 250 lb.: 10A
    • 750 lb.: 30A

Wiring & Installation Diagrams For wiring and installation diagrams, download the BOLT Installation Manual

Installation Manuals & Owners Docs

To find documentation for this product, visit our Owner/Install Manual Library and enter in the part number or product name in the search bar. Here you’ll be able to locate general product information, wiring schematics, installation drilling templates etc.

High Resolution Images

Are you a reseller needing a high resolution image of this product? Simply visit our Image Database and search for the part number or product name.
